Citronic CSP Series Compact Powered Mixers with DSP

£419.00
Add to Wishlist

Safe and secure checkout

apple paygoogle paymaestromasterpaypalshopify payvisa
Ask a Question
SKU: 170.845UK
Availability : In Stock Available from Supplier Out of stock
Description

The powered mixer is a comprehensive audio solution perfect for medium-sized venues, mobile PA systems, bars, and special events. With balanced mic/line inputs and two stereo inputs, each channel is equipped with a 3-band EQ and aux send for versatile sound control. The mixer features a 16-program DSP section with tap tempo for vocal effects and a 7-band graphic EQ for global tone control. Its built-in stereo amplifier delivers sufficient power to drive 2 or 4 speakers, making it an ideal choice for dynamic audio setups.

Specifications

  • DSP Effects: 24-bit, 16 program DSP effects with tap tempo
  • Phantom Power: 48V for XLR inputs
  • EQ per Channel: 3-band EQ (high 12kHz ±15dB shelving, mid 2.5kHz ±15dB band pass, low 80Hz ±15dB shelving)
  • Global EQ: 7-band graphic EQ
  • Power Amplifier: Internal stereo power amplifier
  • Outputs: Balanced main outputs

Technical Details

  • Weight: 10.40kg
  • Dimensions: 477 x 322 x 153mm
  • Inputs:
    • 10 x balanced XLRF/TRS jack mic/line inputs
    • 2-track inputs: 2 x RCA in & out (-2dBu)
  • Output Power:
    • 8 Ohms: 2 x 230W RMS
    • 4 Ohms: 2 x 350W RMS
  • Fuse: T15A (5 x 20mm, 250V)
  • Power Consumption: 1000W
  • Power Supply: 230V AC 50Hz (IEC)
  • Speaker Outputs: L+R SPK connectors
  • Frequency Response: 20Hz-30kHz (±0.5dB)
  • Input Level: +24dBu
  • Output Level: Line +26dBu
  • CMRR: >74dB (mic 1kHz)
  • THD +N: <0.01% (channel to main out)
  • Crosstalk: >85dB (fader mute), >82dB (channel)
  • Noise:
    • RMS: 22Hz-22kHz -122dBu (EIN)
    • -82dBu (mix)
  • Input Impedance:
    • Mic (balanced): 2k Ohms
    • Line (balanced): 10k Ohms
  • Sensitivity:
    • Mic: -60 to +14dBu
    • Line: -40 to +14dBu
  • Output Impedance: <75 Ohms
  • Headphone Output: 6.3mm jack, 30-600 Ohms
